🧊 Ideal for: Walk-in freezers, cold rooms & frozen food storage
⚙️ Power: 4 HP
❄️ Technology: Vapor Injection Scroll
📏 Displacement: 11.7 m³/h @ 50 Hz
📏 Displacement: 14.1 m³/h @ 60 Hz
🌍 Frequency: 50 Hz & 60 Hz options available
⚡ Power Supply: Three-phase options available
🔧 Application: Low-temperature refrigeration
Main Specifications
🔹 Brand: Copeland
🔹 Model: ZFI20KQE
🔹 Nominal Power: 4 HP
🔹 Type: Hermetic Scroll Compressor
🔹 Technology: Vapor Injection
🔹 Displacement @ 50 Hz: 11.7 m³/h
🔹 Displacement @ 60 Hz: 14.1 m³/h
🔹 Application: Low Temperature
🔹 Frequency: 50 Hz / 60 Hz
Voltage Options
Depending on the exact motor code, different electrical configurations are available, including:
⚡ 380–420 V / 3 Phase / 50 Hz
⚡ 460 V / 3 Phase / 60 Hz
⚡ 208–230 V / 3 Phase / 60 Hz
⚡ 380 V / 3 Phase / 60 Hz
Refrigerant Options
Depending on system design and approved operating conditions, the ZFI range can be used with common low-temperature refrigeration refrigerants such as:
• R404A
• R507
• R407A
• R407F
• R448A
• R449A
Typical Applications
❄️ Walk-in freezers
🧊 Low-temperature cold rooms
🥩 Meat & frozen food storage
🐟 Fish & seafood freezers
🏪 Supermarket refrigeration
🍽️ Restaurant freezer rooms
🏭 Food processing refrigeration
📦 Commercial frozen storage
Why Choose Copeland ZFI20KQE?
The ZFI20KQE combines Copeland Scroll technology with vapor injection to provide reliable performance for demanding low-temperature refrigeration applications.
With 50 Hz and 60 Hz options available, it is suitable for refrigeration projects in different international markets.
🌎 Worldwide shipping available
Shipping cost is not included and will be quoted separately according to the destination.
Contact Freezing Valley Refrigeration Equipment for availability, technical information and quotations.
