⚙️ Main Specifications
🔹 Model: ZF41KQE
🔹 Brand: Copeland
🔹 Type: Hermetic Scroll Compressor
🔹 Application: Low-Temperature Refrigeration / Freezer
🔹 Injection Type: Liquid Injection
🔹 Oil Type: POE Oil
🔹 Frequency: 50 Hz / 60 Hz versions available
🔹 3-Phase Options: Available
❄️ Refrigerant Options
According to the supplied Copeland catalogue, the ZF/ZFI range is qualified for:
🔹 R404A / R507
🔹 R407A / R407C / R407F
🔹 R448A / R449A
🔹 R22
🌡️ Typical Applications
🧊 Walk-In Freezers
🥩 Frozen Meat Storage
🐟 Fish & Seafood Freezers
🍗 Frozen Food Storage
🏪 Supermarket Refrigeration
🏭 Food Processing & Industrial Refrigeration
❄️ Large Low-Temperature Cold Rooms
The ZFKQ range is designed for demanding low-temperature refrigeration, with the overall family capable of operating down to approximately −40°C evaporating temperature, subject to the refrigerant and operating conditions.
📊 R404A Cooling Capacity – 50 Hz
For ZF41KQE at 40°C condensing temperature, the catalogue provides:
| Evaporating Temperature |
Cooling Capacity |
| −40°C |
5.80 kW |
| −35°C |
7.40 kW |
| −30°C |
9.27 kW |
| −25°C |
11.46 kW |
| −20°C |
14.03 kW |
| −15°C |
17.01 kW |
| −10°C |
20.46 kW |
| −5°C |
24.42 kW |
Copeland-scroll-compressors-zfkq-for-refrigeration-applications-catalogue.pdfPDF
⚡ 50 Hz & 60 Hz Available
🌏 50 Hz — Suitable for New Zealand, Australia, Europe, the Middle East and many Asian markets.
🌎 60 Hz — Suitable for the USA, Canada and other 60 Hz markets.
Different voltage and motor configurations are available depending on the exact compressor version and destination market.
⭐ Key Features
✅ Designed for low-temperature/freezer applications
✅ Liquid injection for discharge-temperature control
✅ Available in 50 Hz & 60 Hz
✅ Multiple approved refrigerant options
✅ High refrigeration capacity
✅ Compact Copeland Scroll design
✅ Suitable for larger commercial & industrial refrigeration systems
✅ Suitable for walk-in freezers and frozen-food cold storage
Selection Note: Actual refrigeration capacity depends on the evaporating temperature, condensing temperature, refrigerant and system operating conditions. Compressor selection should be based on the required cooling load rather than HP alone.
