⚙️ Main Specifications
🔹 Model: ZF25KQE
🔹 Brand: Copeland
🔹 Type: Hermetic Scroll Compressor
🔹 Application: Low-Temperature Refrigeration / Freezer
🔹 Injection Type: Liquid Injection
🔹 Oil Type: POE Oil
🔹 Frequency: 50 Hz / 60 Hz versions available
🔹 3-Phase Options: Available
❄️ Refrigerant Options
The catalogue qualifies the ZF/ZFI family for:
🔹 R404A / R507
🔹 R407A / R407C / R407F
🔹 R448A / R449A
🔹 R22
🌡️ Typical Applications
🧊 Walk-In Freezers
🥩 Frozen Meat Storage
🐟 Fish & Seafood Freezers
🍗 Frozen Food Storage
🏪 Supermarket Refrigeration
🏭 Food Processing & Industrial Refrigeration
The ZFKQ range is designed for demanding low-temperature refrigeration, with the overall series having an application envelope extending down to approximately −40°C evaporating temperature, depending on refrigerant and operating conditions.
📊 R404A Cooling Capacity – 50 Hz
For ZF25KQE at 40°C condensing temperature, your Copeland catalogue gives:
| Evaporating Temp. |
Cooling Capacity |
| −40°C |
3.73 kW |
| −35°C |
4.74 kW |
| −30°C |
5.95 kW |
| −25°C |
7.39 kW |
| −20°C |
9.09 kW |
| −15°C |
11.06 kW |
| −10°C |
13.34 kW |
| −5°C |
15.96 kW |
⚡ 50 Hz & 60 Hz Available
🌏 50 Hz — Suitable for New Zealand, Australia, Europe, Middle East and many Asian markets.
🌎 60 Hz — Suitable for the USA, Canada and other 60 Hz markets.
For example, the catalogue identifies the TFD electrical code as 380–420 V, 3-phase at 50 Hz and 460 V at 60 Hz. Copeland-scroll-compressors-zfkq-for-refrigeration-applications-catalogue.pdfPDF
⭐ Key Features
✅ Designed for low-temperature/freezer applications
✅ Liquid injection for discharge-temperature control
✅ Available in 50 Hz & 60 Hz
✅ Multiple refrigerant options
✅ Compact Copeland Scroll design
✅ Suitable for commercial & industrial refrigeration
✅ Ideal for larger freezer and frozen-food applications
Important: Your supplied catalogue confirms the ZF25KQE model and its performance data, but the excerpts available here do not establish a nominal HP rating, so I would not put an HP figure on your website until we verify it from Copeland's technical/model data.
